North America Model 8000Btu, R410a, 115V/ 60Hz, ETL certificate

Basic features :

1- 4 Castors makes moving convenient

2- 3 adjustable steps of “cooling function / fan”

3- 3 in 1, fan, cooling and dehumidifying

4- Automatically swing

6- 24 hour ON/OFF function

7- Water full alert

8- Self-evaportative system, water generated inside is reused

9- 3-minute delay compressor restarts protection function

10- Removable filter

11- LCD display indicating temperature and operation status

12- With remote control

13- Lots of humanism design. Remote control and power plug could be put aside   in the rear of the machine after use. Exhaust hose and window kit could be fixed   with the machine after use.

14- Wind outlet closes automatically after the unit is turned off to prevent dirt into machine.

15- Large loading quantity, rather low shipping cost.

Specifications:

Model No.:                            YPN-10H          YPN-12H

Cooling Capacity (Btu/h)/      10,000               12,000

Heating Capacity (Btu/h)/      11,000               13,000

Power supply             115V/60Hz

Reted input (cooling) W:         1000                 1350

Reted current (cooling) A:        9.6                    10.9

Reted input (heating)/              9000                  1280

Reted current (heating)/           9.6                    10.9

EER Btu/W.h                            8.9                     8.9

                W/W                         2.61                   2.61

COP for cooling(R410A)

Btu/W.h:                                     9.6                  9.6

W/W                                           2.8                   2.8

Moisture Removel (L/h): 1.2

Air circulation (m3/h):      450

Noise    dB(A)High:         56

Middle:                             54

Low:                                 52

Body size (mm): 470×845×330

Package size (mm): 530×874×385

Net weight (Kg)                             29                 33

Unit Color: White, Silver

Gross weight (Kg)                        33                   37

Application area (m2):   20~25

Loading quantity (pcs)20'/ 40GP/ 40HQ: 132/ 264/ 396 pcs

 Remark: Class A udner new ERP

Accessories:

1- Air exhaust duct x 1 piece (1.5 meters with connector)

2- Window sealing board x 1 set

3- Window sealing zipper mat(optional)  + connector for air exhaust duct x 1 set

4- Users manual

5- Remote control

Certifications: CE, GS, EMC

Compliant materials：ROHS  PAHS
